Semantic Analysis

semantics concerns its meaning. Meaning is important for at least two reasons: it allows us to enforce rules (e.g., type consistency) that go beyond mere form, and it provides the information we need in order to generate an equivalent output program.

Semantic rules are further divided into static and dynamic semantics

Both semantic analysis and intermediate code generation can be described in terms of annotation, or decoration of a parse tree or syntax tree.

Attribute grammars provide a formal framework for the decoration of a tree. This framework is a useful conceptual tool even in compilers that do not build a parse tree or syntax tree as an explicit data structure.

The Role of the Semantic Analyzer

The role of the semantic analyzer is to enforce all static semantic rules and to annotate the program with information needed by the intermediate code generator.

Dynamic Checks

Many compilers that generate code for dynamic checks provide the option of disabling them if desired.

Assertions

The compiler then generates code to check the assertions at run time. An assertion is a statement that a specified condition is expected to be true when execution reaches a certain point in the code.

Static Analysis

In general, compile-time algorithms that predict run-time behavior are known as static analysis.

static analysis may enable code improvement:

  • alias analysis
  • escape analysis
  • subtype analysis

Attribute Grammars

To tie these expressions to mathematical concepts (as opposed to, say, floor tile patterns or dance steps), we need additional notation. The most common is based on attributes.

In a compiler or interpreter for a full programming language, the attributes of tree nodes might include:

  • for an identifier, a reference to information about it in the symbol table
  • for an expression, its type
  • for a statement or expression, a reference to corresponding code in the compiler’s intermediate form
  • for almost any construct, an indication of the file name, line, and column where the corresponding source code begins
  • for any internal node, a list of semantic errors found in the subtree below

Evaluating Attributes

The process of evaluating attributes is called annotation or decoration of the parse tree.

Synthesized Attributes 合成属性

synthesized attributes: their values are calculated (synthesized) only in productions in which their symbol appears on the left-hand side.

Inherited Attributes

In general, we can imagine (and will in fact have need of) attributes whose values are calculated when their symbol is on the right-hand side of the current production. Such attributes are said to be inherited.

Attribute Flow

they define a set of valid trees, but they don’t say how to build or decorate them.

the order in which attribute rules are listed for a given production is immaterial; attribute flow may require them to execute in any order.

An algorithm that decorates parse trees by invoking the rules of an attribute grammar in an order consistent with the tree’s attribute flow is called a translation scheme.

One-Pass Compilers

A compiler that interleaves semantic analysis and code generation with parsing is said to be a one-pass compiler

Action Routines

An ad hoc translation scheme that is interleaved with parsing takes the form of a set of action routines.

An action routine is a semantic function that the programmer (grammar writer) instructs the compiler to execute at a particular point in the parse.

Space Management for Attributes

If we are building an explicit parse tree, then the obvious approach is to store attributes in the nodes of the tree themselves.

For a bottom-up parser with an S-attributed grammar, the obvious approach is to maintain an attribute stack

For a top-down parser with an L-attributed grammar, we have two principal options:

  • uses an attribute stack
  • “shortcutting” copy rules

Tree Grammars and Syntax Tree Decoration

attribute grammars can also be used to decorate syntax trees.

Summary and Concluding Remarks

本章讨论了语义分析的任务。我们回顾了可以分类为语法、静态语义和动态语义的语言规则类型,并讨论了是否生成代码以执行动态语义检查的问题。我们还考虑了语义分析器在典型编译器中的作用。我们指出,静态语义规则的执行和中间代码的生成都可以用解析树或语法树的注释或装饰来表达。然后,我们提出了属性文法作为这个装饰过程的形式化框架。

属性文法将属性与上下文无关文法或树文法中的每个符号关联,并将属性规则与每个产生式关联起来。在上下文无关文法中,综合属性只在其符号出现在产生式的左侧时计算。标记的综合属性由扫描器初始化。继承属性在其符号出现在右侧的产生式中计算;它们允许符号下子树中的计算依赖于符号出现的上下文。起始符号(目标)的继承属性可以表示编译器的外部环境。严格来说,属性文法只允许复制规则(一个属性分配给另一个属性)和对语义函数的简单调用,但我们通常放宽这一限制,以允许在某些现有编程语言中使用更多或更少任意的代码片段。

就像上下文无关文法可以根据可以使用它们的解析算法进行分类一样,属性文法可以根据其属性流模式的复杂性进行分类。在S-属性文法中,所有属性都是综合的,可以自然地在解析树上进行单次自底向上遍历,按照LR族解析器发现树的顺序精确计算。在L-属性文法中,所有属性流都是深度优先从左到右的,可以按照LL族解析器预测和匹配解析树的顺序精确计算。具有更复杂属性流模式的属性文法通常不用于生成编译器的解析树,但对于基于语法的编辑器、增量编译器和其他各种工具非常有价值。

虽然可以构建自动工具来分析属性流并装饰解析树,但大多数编译器依赖于动作例程,编译器编写者将这些例程嵌入到产生式的右侧,以在解析的特定点评估属性规则。在LL族解析器中,动作例程可以嵌入到产生式右侧的任意点。在LR族解析器中,动作例程必须遵循产生式的左角。自底向上编译器中的属性空间自然地与解析栈并行分配,但这使得继承属性的管理变得复杂。自顶向下编译器中的属性空间可以自动分配,或由动作例程的编写者显式管理。自动方法具有规律性的优势,并且更易于维护;而临时方法略快且更灵活。

在单遍编译器中,扫描、解析、语义分析和代码生成在对输入的单次遍历中交替进行。语义函数或动作例程负责所有的语义分析和代码生成。更常见的做法是,动作例程仅构建一个语法树,然后在后续的单独遍历中对其进行装饰。这些遍历的代码通常是手工编写的,以相互递归的子程序形式,使得编译器可以在语法树上实现基本上任意的属性流。

在接下来的章节(特别是第6至第10章),我们将考虑各种各样的编程语言构造。我们不会呈现实现这些构造所需的实际属性文法,而是会以非正式的方式描述它们的语义,并给出目标代码的示例。在第15章中,当我们更详细地考虑中间代码生成时,我们将回顾属性文法。

Names, Scopes, and Bindings

A name is a mnemonic character string used to represent something else.

Names allow us to refer to variables, constants, operations, types, and so on using symbolic identifiers rather than low-level concepts like addresses.

Subroutines are control abstractions.

Classes are data abstractions.

The Notion of Binding Time

the notion of binding time, which refers not only to the binding of a name to the thing it represents, but also in general to the notion of resolving any design decision in a language implementation.

通常,早期绑定时机与更高的效率相关,而后期的绑定时机与更大的灵活性相关。

不同的东西的绑定时机是不一样的:

  • Language design time:控制流结构,基本类型,复杂对象组织方法等语义方面的内容
  • Language implementation time:基础类型大小,和操作系统交互,堆和栈的组织方式和大小
  • Program writing time:算法,数据结构,命名
  • Compile time:高级数据结构和机器码的映射,静态数据的内存布局
  • Link time:引用其他的模块的绑定关系到链接时才能确定(增量编译)
  • Load time:程序装载时才能确定实际的地址(虚实地址转换)
  • Run time:变量值绑定,程序启动时机,模块装载时机,首次“看到”声明的时机,子程序调用时机,代码块进入时机,表达式求值、语句执行时机

Compiler-based language implementations tend to be more efficient than interpreter-based implementations because they make earlier decisions.

Object Lifetime and Storage Management

The period of time between the creation and the destruction of a name-to-object binding is called the binding’s lifetime.

生命周期管理不正确肯能会导致“悬挂指针”

对象的生命周期取决于存储分配机制(对象空间):

  • 静态对象(绝对地址)
  • 栈对象(栈上分配,通常在子程序调用)
  • 堆对象(随时分配)

Static Allocation

Global variables are the obvious example of static objects, but not the only one.

Numeric and string-valued constant literals are also statically allocated.

Finally, most compilers produce a variety of tables that are used by run-time support routines for debugging, dynamic type checking, garbage collection, exception handling, and other purposes; these are also statically allocated.

Manifest constants can always be allocated statically, even if they are local to a recursive subroutine: multiple instances can share the same location.

Stack-Based Allocation

If a language permits recursion, static allocation of local variables is no longer an option.

Fortunately, the natural nesting of subroutine calls makes it easy to allocate space for locals on a stack.

Each instance of a subroutine at run time has its own frame (also called an activation record) on the stack, containing arguments and return values, local variables, temporaries, and bookkeeping information.

Heap-Based Allocation

A heap is a region of storage in which subblocks can be allocated and deallocated at arbitrary times.

Heaps are required for the dynamically allocated pieces of linked data structures, and for objects such as fully general character strings, lists, and sets, whose size may change as a result of an assignment statement or other update operation.

The principal concerns are speed and space, and as usual there are tradeoffs between them.

堆内存管理方法:

  • With a first fit algorithm we select the first block on the list that is large enough to satisfy the request.
  • With a best fit algorithm we search the entire list to find the smallest block that is large enough to satisfy the request.

两者的对比:

Intuitively, one would expect a best fit algorithm to do a better job of reserving large blocks for large requests. At the same time, it has higher allocation cost than a first fit algorithm, because it must always search the entire list, and it tends to result in a larger number of very small “left-over” blocks.

内存管理存在的问题:

内存分配效率和堆最小大小有关(多次申请):

In effect, the heap is divided into “pools,” one for each standard size. The division may be static or dynamic. Two common mechanisms for dynamic pool adjustment are known as the buddy system and the Fibonacci heap.

内存碎片问题:

The problem with external fragmentation is that the ability of the heap to satisfy requests may degrade over time.

Garbage Collection

The run-time library for such a language must then provide a garbage collection mechanism to identify and reclaim unreachable objects.

手动 vs 自动:

  • The traditional arguments in favor of explicit deallocation are implementation simplicity and execution speed.
  • manual deallocation errors are among the most common and costly bugs in real-world programs.

Scope Rules

The textual region of the program in which a binding is active is its scope. In most modern languages, the scope of a binding is determined statically, that is, at compile time.

作用域分为:

  • statically scoped: compile time
  • dynamically scoped: bindings depend on the flow of execution at run time

At any given point in a program’s execution, the set of active bindings is called the current referencing environment. The set is principally determined by static or dynamic scope rules.

binding rules:

  • deep binding: the choice is made when the reference is first created
  • shallow binding: the choice is made when the reference is finally used

Static Scoping

In a language with static (lexical) scoping, the bindings between names and objects can be determined at compile time by examining the text of the program, without consideration of the flow of control at run time.

Nested Subroutines

a name that is introduced in a declaration is known in the scope in which it is declared, and in each internally nested scope, unless it is hidden by another declaration of the same name in one or more nested scopes.

To find the object corresponding to a given use of a name, we look for a declaration with that name in the current, innermost scope. If there is one, it defines the active binding for the name. Otherwise, we look for a declaration in the immediately surrounding scope.

A name-to-object binding that is hidden by a nested declaration of the same name is said to have a hole in its scope.

作用域解析运算符:

In others, the programmer can access the outer meaning of a name by applying a qualifier or scope resolution operator.

Declaration Order

Put another way, can an expression E refer to any name declared in the current scope, or only to names that are declared before E in the scope?

Several early languages, required that all declarations appear at the beginning of their scope.

C++ and Java further relax the rules by dispensing with the define-before-use requirement in many cases. In both languages, members of a class (including those that are not defined until later in the program text) are visible inside all of the class’s methods.

Declarations and Definitions

如何处理两个类互相包含彼此?

Recursive types and subroutines introduce a problem for languages that require names to be declared before they can be used: how can two declarations each appear before the other?

  • A declaration introduces a name and indicates its scope, but may omit certain implementation details.
  • A definition describes the object in sufficient detail for the compiler to determine its implementation.

Modules

模块化和信息隐藏,减少认识负荷:

This modularization of effort depends critically on the notion of information hiding, which makes objects and algorithms invisible, whenever possible, to portions of the system that do not need them.

Module Types and Classes

An alternative solution to the multiple instance problem appeared in Euclid, which treated each module as a type. Given a module type, the programmer could declare an arbitrary number of similar module objects.

Dynamic Scoping

In a language with dynamic scoping, the bindings between names and objects depend on the flow of control at run time, and in particular on the order in which subroutines are called.

为什么动态作用域到运行时才能确定?

Because the flow of control cannot in general be predicted in advance, the bindings between names and objects in a language with dynamic scoping cannot in general be determined by a compiler.

Implementing Scope

To keep track of the names in a statically scoped program, a compiler relies on a data abstraction called a symbol table.

In a language with dynamic scoping, an interpreter (or the output of a compiler) must perform operations analogous to symbol table insert and lookup at run time.

The Meaning of Names within a Scope

A name that can refer to more than one object at a given point in the program is said to be overloaded. Overloading is in turn related to the more general subject of polymorphism.

  • aliases: Two or more names that refer to the same object at the same point in the program are said to be aliases.
  • overloaded: A name that can refer to more than one object at a given point in the program is said to be overloaded
  • Redefining Built-in Operators

The Binding of Referencing Environments

When should scope rules be applied to such a subroutine: when the reference is first created, or when the routine is finally called?

动态作用域常使用 shallow binding:

This late binding of the referencing environment of a subroutine that has been passed as a parameter is known as shallow binding.

静态作用域常使用 deep binding:

It therefore makes sense to bind the environment at the time the routine is first passed as a parameter, and then restore that environment when the routine is finally called.

This early binding of the referencing environment is known as deep binding.

Subroutine Closures

Deep binding is implemented by creating an explicit representation of a referencing environment (generally the one in which the subroutine would execute if called at the present time) and bundling it together with a reference to the subroutine. The bundle as a whole is referred to as a closure.

Object Closures

An object that plays the role of a function and its referencing environment may variously be called an object closure, a function object, or a functor.

Macro Expansion

Prior to the development of high-level programming languages, assembly language programmers could find themselves writing highly repetitive code. To ease the burden, many assemblers provided sophisticated macro expansion facilities.

So-called hygienic macros(卫生宏) implicitly encapsulate their arguments, avoiding unexpected interactions with associativity and precedence.

Summary and Concluding Remarks

这一章讨论了名称的主题,以及名称与对象的绑定(在广义上)。我们开始从绑定时间的一般讨论——名称与特定对象关联的时间,或更一般地说,任何开放问题在语言或程序设计或实现中与答案关联的时间。我们定义了对象和名称到对象绑定的生命周期的概念,并指出它们不必相同。然后,我们介绍了三种主要的存储分配机制——静态、栈、和堆——用于管理对象的空间。

在3.3节中,我们描述了名称与对象的绑定是如何受作用域规则的约束。在一些语言中,作用域规则是动态的:一个名称的含义是在最近进入的包含声明且尚未退出的作用域中找到的。然而,在大多数现代语言中,作用域规则是静态的,或者说是词法的:一个名称的含义是在最近的包含声明的词法环绕作用域中找到的。我们发现,词法作用域规则在不同语言之间以重要但有时是微妙的方式变化。我们考虑了哪些类型的作用域是允许嵌套的,作用域是开放的还是封闭的,一个名称的作用域是否包括其声明的整个块,以及是否必须在使用名称之前声明它。我们在3.4节探索了作用域规则的实现。

在3.5节中,我们检查了绑定之间关系的几种方式。别名产生于当在给定作用域中两个或更多名称绑定到同一个对象时。重载产生于一个名称绑定到多个对象时。我们注意到,尽管有时可以通过强制转换或多态性实现类似重载的行为,但底层机制实际上是非常不同的。在3.6节中,我们考虑了何时将引用环境绑定到作为参数传递、从函数返回或存储在变量中的子程序的问题。我们的讨论涉及了闭包和lambda表达式的概念,这两者在后续章节中都会反复出现。在3.7节和3.8节中,我们考虑了宏和分离编译。

词法作用域的一些更复杂的方面说明了对数据抽象的语言支持的发展,这是我们将在第10章回顾的主题。我们首先描述了像Fortran、Algol 60和C这样的语言中的own或静态变量,这些变量允许子程序中的局部变量在一次调用到下一次调用时保持其值。然后我们注意到,简单模块可以被看作是一种使长期存在的对象对一组子程序局部化的方式,这样它们对程序的其他部分来说是不可见的。通过选择性地导出名称,一个模块可以作为一个或多个抽象数据类型的“管理者”。在更高一层的复杂性中,我们注意到有些语言将模块视为类型,允许程序员创建由模块定义的抽象的任意数量的实例。最后,我们注意到面向对象语言通过提供一个继承机制,这个机制允许定义新的抽象(类)作为现有类的扩展或精化,从而扩展了模块作为类型的方法(以及词法作用域的概念)。

在本章考虑的主题中,我们看到了一些有用的特性的例子(递归、静态作用域、前向引用、一级子程序、无限范围),这些特性因为担心实现的复杂性或运行时成本而被某些语言省略。我们还看到了一个特性的例子(模块规范的私有部分),它是为了方便语言的实现而特别引入的,以及另一个(C语言中的独立编译)其设计显然是为了反映特定的实现。在语言设计的几个额外方面(晚绑定与早绑定、静态与动态作用域、对强制转换和转换的支持、对指针和其他别名的容忍),我们看到实现问题起着重要作用。

在类似的脉络中,看似简单的语言规则可能会有出人意料的含义。例如,在3.3.3节中,我们考虑了整个块作用域与名字必须在使用前声明的要求之间的相互作用。就像Fortran的do循环语法和空白规则(2.2.2节)或Pascal的if…then…else语法(2.3.2节),如果选择不当,作用域规则会使程序分析变得困难,这不仅对编译器如此,对人类同样如此。在未来的章节中,我们将看到几个既令人困惑又难以编译的特性示例。当然,语义的实用性和实现的容易程度并不总是一致的。许多容易编译的特性(例如,goto语句)其价值至少是值得怀疑的。我们还将看到几个非常有用且(概念上)简单的特性,比如垃圾收集(8.5.3节)和统一(7.2.4节,C 7.3.2节和12.2.1节),它们的实现却相当复杂。

因为目前博客的主题在文字排版上总感觉有一些问题,再加上想做一个个人的知识整合网站于是就开始折腾Docusaurus。

创建项目

  1. 新建一个GitHub仓库,使用codespace打开。
  2. 在命令行中初始化docusaurus
    1
    2
    npx create-docusaurus@latest my-knowledge-repo classic --typescript
    npm run start
  3. 将文件移动到当前目录:mv my-knowledge-repo/* .
  4. 提交变更,初始化完成

Github Action + Github Pages

根据官方文档Triggering deployment with GitHub Actions操作。

docusaurus.config.ts

除了一些网站的基本描述配置之外还有一些值得注意的配置项:

上方navebar项目配置:Navbar items

代码高亮

1
2
3
4
5
6
7
8
9
10
11
12
13
prism: {
additionalLanguages: [
'java',
'latex',
'haskell',
'matlab',
'PHp',
'bash',
'diff',
'json',
'scss',
],
}

使用官方文档作为例子:

sidebars.ts
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
const sidebars: SidebarsConfig = {
technical: [
'technical/introduction',
{
label: 'Programming Language Pragmatics',
type: 'category',
link: {
type: 'generated-index',
title: 'Programming Language Pragmatics',
description:
"Programming Language Pragmatics笔记",
},
items:[
'technical/programming-language-pragmatics/01',
'technical/programming-language-pragmatics/02'
],
}
],
life: [{type: 'autogenerated', dirName: 'life'}],
};
docusaurus.config.ts
1
2
3
4
5
6
items: [
{
label: 'Technical',
to: 'docs/technical',
},
]

MDX语法

警告:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
:::note

Some **content** with _Markdown_ `syntax`. Check [this `api`](#).

:::

:::tip

Some **content** with _Markdown_ `syntax`. Check [this `api`](#).

:::

:::info

Some **content** with _Markdown_ `syntax`. Check [this `api`](#).

:::

:::warning

Some **content** with _Markdown_ `syntax`. Check [this `api`](#).

:::

:::danger

Some **content** with _Markdown_ `syntax`. Check [this `api`](#).

:::
